Main technical parameter
1. Chassis: 250mm U-steel structural steel welding
2. Forming type: chain drive
3. Diameter of axle: ￠65mm
4. Chain:16A
5. Forming motor power：5.5kw
6. Forming speed：8-15m/min
7. Forming rollers：12 steps
8. Roller material：45#steel, coated hard chrome
9. Thickness of coated hard chrome：0.05mm
10. Hydraulic station motor：3kw
11. Hydraulic oil pump：gear pump
12. Cutting type：hydroform cutter
13. Material of cutting part：Cr12,heat treatment HRC58°-60°
14. Thickness of coils：0.5-1.3mm
15. Length scale precision：±2mm
16. Transducer: YASKAWA
17. Controlling system: PLC ,touch screen
18. Power:220V 60HZ 3 phase,15KW electric generator
19. Size：5500mmx1500mmx2000mm
20. Weight:5 tons |
