Main parameter
1. De-coiler: manual operation, passively de-coiling
2. Loading of de-coiler: 5 T
3. Frame of machine: welded with 350H beam steel
4. Guide feeding way of forming: side direction roller type
5. Forming machine type: wallboard and chain drive
6. Diameter of shaft: ￠76mm
7. Chain: 16A single row
8. Motor power of forming machine: 5.5KW
9. Line speed of forming machine: 5-17m/min
10. Steps of forming machine: 18
11. Roller material: superior 45# steel forging
12. Thickness of Chrome plated on roller: 0.05mm
13. Hydraulic station motor: 4 KW
14. Hydraulic station oil pump: gear pump
15. Cutting way: cut off after hydraulic shaped
16. Cutting blade material: Cr12
17. Cutting blade heat treatment: HRC58?-60
18. Rolling thickness: 0.4-0.8 mm
19. Feeding width: 1250mm
20. Precision of cut-to-length: ±2mm
21. Frequency changer : Panasonic
22. Computer adopts PLC : Panasonic
23. Dimension of machine: 8.5M x 1.6M x 0.8M
Technological process
Passively de-coiling → Guiding & Feeding material → Roll Forming → Cutting-to-length → Output panel
Equipment configuration
|
No. |
Item |
Qty. |
|
1 |
Passive de-coiler |
1 piece |
|
2 |
Roll forming machine |
1 piece |
|
3 |
Hydraulic cutting blade |
1 set |
|
4 |
Hydraulic station |
1 piece |
|
5 |
Computer control counter |
1 piece |
|
6 |
Run out table |
3 pieces | |
