BH Slitting line
Specification parameter
a. Application materials: cold/hot rolled coils
b. Materials standard: Domestic steel sheet or international standards
c. Strength of extension: b≤450Mpa,δS≤260Mpa,
d. Thickness of materials: 0.5-2.5mm,
e. Width of materials: 500-1500(Max)
f.  Steel coil inner diameter: ф508
g. Steel coil outer diameter: ф1500(Max)
h. Steel coil weight: 15000kg
i.  The vertical scissors shaft diameter: ф180  Materials: 50Cr
j.  The vertical scissors: ф180×ф320×15
k. Materials of the vertical scissors: 9SiCr
