   BH-240 Arch Sheet Roll Forming Machine
1000-800 Large Span Roof Roll Forming Machine



The drawing of BH-1000-800

Main Technical Specification:
Size: 11650mm × 2230mm × 2300mm
Total Weight: about 15000KG
Feeding Width: 1000mm
Effective Width: 800mm
Proper span: ≤18m
Sheet operating factor: 80%





Total MotorPower:18.9KW
Bending power: 3.0kw+1.1kwx2;                         Sewing power: 2.2kw
Cutting power: 4.0kw;
Forming power: 7.5kw
Controlling system: PLC&Manual
Cutting: Mechanical cutting
The depth of the groove:114mm
Equipped with generator
Material of roller shaft: 45# steel, galvanized
Material of rollers: 45# steel, quenched with hard chrome
